Industrial Grade Development Kit
MediaTek LinkIt 2523 Development Board
RICHTEK Module Products
ST SSC Zone
X-NUCLEO-GFX02Z1
[Oct NPI] features a 2.2” 8-bit parallel interface TFT display as well as a 64-Mbit Q-SPI NOR Flash memory for storing graphic images, texts and texture. The expansion board also offers a joystick for GUI navigation.X-NUCLEO-GFX02Z1 features the Zio connector.
AEK-MOT-3P99081
[Oct.NPI] is based on the SPC560P Pictus 32-bit MCU and the L9908 gate driver allowing the control of 6 N-channel FETs for brushless motors in automotive applications and supports independent encoder inputs and Hall sensors to detect and
STEVAL-MKI210V2K
[Sep.NPI] includes the STEVAL-MKI210V2 main board and the STEVAL-MKIGIBV5 adapter board. The main board embeds the ISM330DHCX 3D accelerometer and 3D gyroscope sensor and...
STEVAL-NRG011TV
[Aug. NPI] The design is based on the STNRG011 IC digital combo controller that controls a two-stage AC/DC SMPS. The front-end is a transition mode PFC pre-regulator and the second stage is an LLC HB resonant converter.
AEK-COM-GNSST31
[Aug. NPI]is based on the certified Teseo-LIV3F global navigation satellite system (GNSS) module with embedded TeseoIII single die standalone positioning receiver IC. The tiny, affordable, and easy-to use module guarantees...
STEVAL-IFP035V1
[Aug. NPI]is designed to help you evaluate circuit protection strategies for factory automation using digital-input current limiters between industrial sensor devices and processing units such as programmable logic controllers (PLC).
STEVAL-AETKT2V1
[Aug. NPI] implements bidirectional current sense amplifiers by placing a sense resistor either in the high-side or in the low-side. The STEVAL-AETKT2V1 kit consists of a motherboard and two different daughter boards for different gain configurations.
STEVAL-ETH001V1
[Jul. NPI] has been developed to address three-phase PMSM applications oriented to multi-axial position control and connectivity. The evaluation board embeds a motor control power stage, a digital actuation section and a power management section
X-NUCLEO-SNK1M1
[Jul. NPI] expansion board allows evaluating the features of TCPP01-M12 and the USB Type-C overvoltage protection for VBUS and CC lines suitable for Sink applications.It is designed to be stacked
STEVAL-VP12201F
[Jun. NPI] developed for general purpose applications supplied from 85 to 265 VAC and is built around the new VIPer122LS offline high-voltage converter from the VIPerPlus family, with embedded 730 V Power MOSFET and PWM current-mode control.
AEK-MOT-2DC70S1
[Jun. NPI] is a very compact solution for multi DC motor driving applications, embedding all the driver and signal decoding functions on the same board.Together with current sensing capability , the AEK-MOT-2DC70S1...
NUCLEO-L433RC-P
The STM32 Nucleo-64-P boards (NUCLEO-L412RB-P, NUCLEO-L433RC-P and NUCLEO-L452RE-P) provide an affordable and flexible way for users to try out new concepts
X-NUCLEO-IKS01A3
is a motion MEMS and environmental sensor evaluation board system. It is compatible with the Arduino UNO R3 connector layout and features the LSM6DSO 3-axis accelerometer + 3-axis gyroscope, the LIS2MDL 3-axis magnetometer,
X-NUCLEO-CCA01M1
is an expansion board based on the STA350BW Sound Terminal® 2.1-channel high-efficiency digital audio output system.It can be plugged on top of an STM32 Nucleo board and is compatible with the ST morpho connector layout.
VL6180X-SATEL
The satellite boards are hardware addons for the X-NUCLEO-6180XA1 expansion board. Up to 3 satellite boards can be connected to the X-NUCLEO-6180XA1 expansion board, enabling multi sensors applications.
STEVAL-MKI194V1
is an adapter board designed to facilitate the evaluation of MEMS devices in the LSM6DSR product family. The board offers an effective solution for fast system prototyping and device evaluation directly within the user’s own application.
STEVAL-MKI182V2
is an adapter board designed to facilitate the evaluation of MEMS devices in the ISM330DLC product family. The board offers an effective solution for fast system prototyping and device evaluation directly within the user’s own application.
STEVAL-MKI181V1
is an adapter boarddesigned to facilitate the evaluation of MEMS devices in the LIS2MDL product family. Theboard offers an effective solution for fast system prototyping and device evaluation directly within the user's own application.
STEVAL-FKI433V2
is based on the S2-LP sub-1GHz ultra-low power low data-rate transceiver suitable for ISM bands and wireless M-Bus.The NUCLEO-L053R8 motherboard is equipped with an STM32L0 low power microcontroller to control the S2-LP.
STEVAL-FKI001V1
development kit is a cost-effective tool to help you design solutions based on Sigfox™, Bluetooth® low energy and sub-1GHz technologies.The kit features a fully programmable module WS2118 (by Jorjin),
AEK-CON-SENSOR1
is designed to interface MEMS sensor boards in DIL 24 socket to an SPC5 MCU discovery board like the AEK-MCU-C4MLIT1 hosting a SPC58EC80E5 Chorus family automotive MCU with 4 MB flash.
STEVAL-MKI209V1K
has an embedded IIS2ICLX inclinometer sensor, which is connected through flat cable to a simple adapter board (STEVALMKIGIBV2) to render it compatible with STEVAL-MKI109V3.
RSL10-SENSE-DB-GEVK
is a comprehensive, compact, node−to−cloud IoT sensor platform that allows development of various Bluetooth Low Energy based use cases. Along with the hardware and software, it includes a mobile...
BLE-SWITCH001-GEVB
The Energy Harvesting Bluetooth Low Energy Switch reference design is battery-free Bluetooth switch based on the RSL10 SIP, the the industry’s lowest power Bluetooth 5 radio integrated into a complete System-in-Package (SiP) solution.
AR0234CSSM00SUKAH3-GEVB
旨在演示與開發安森美圖像感測器AR0234CSSM產品。開發版需要搭配 demo3 主機板與 DevWareX 軟體使用，可以節省模組前期研發時程,以及後續影像調教
AR0234CSSC00SUKAH3-GEVB
旨在演示與開發安森美圖像傳感器AR0234CSSM產品。 開發版需要搭配 demo3 主板與 DevWareX 軟體使用可以節省模組前期研發時程,以及後續影像調教
SPSDEVK1-PET-GEVK
本商品提供了有關無電池智能無源傳感器統包方案套件 的配置和使用。 SPSDEVK1MT提供完整的解決方案套件，能夠快速安裝完整的智慧無源感測器™系統。
LV8310HGR2G12VGEVK
除LV8310外同時搭載二顆FW389 P+N MOS線路最為精簡。可程式化調整超前角功能讓使用者在搭配不同規格馬達及不同應用轉速，均能套用同一電子料；市售同等品需有不同的超前角電阻配置故無法完全共料。建議最大操作條件在12V／10A單相有傳感器電機。
LC823455XGEVK
describes the hardware board of the LC823455 evaluation kit to help you understand the functions and schematics of the board. The block diagrams help you understand large scale schematics.
SECO-NCV7685RGB-GEVB
is an evaluation board for RGB LEDs lighting application with BLE in automotive which driven by NCV7685 and controlled by RSL10. It is also an interior or exterior lighting reference design for tail or ambient lights to realize general...
NCP1083WIRGEVB
implements a PoE module DC/DC converter that converts the higher voltage one the Ethernet cable to a lower voltage (12 V) with power levels up to 30W. Detection, classification and power up sequence is implemented according to IEEE802.3at (D4)
LC823450XGEVK
is an evaluation board for LC823450 Series (called LC823450 hereafter) which is a low power & high-resolution audio processing system LSI for portable sound solution. This user’s manual describes the method of writing firmware of the evaluation board
RSL10-USB001GEVK
為藍牙和低功耗設備®外設實現快速原型設計。使用隨附的藍牙®低能耗資源管理器軟體,工程師可以快速輕鬆地開發、測試和評估基於藍牙的應用程式。使用 2 Mbps 連接,RSL10 USB Dongle在開發過程中充當通用中央設備
2.C9303AA2000.A
晉弘科技採用類半導體製程的全自動化技術，將照明系統與鏡頭模組一體化封裝成微型鏡頭照明模組。此模組採用微型化設計，多樣的封裝樣式可供業界不同內視鏡的應用，更適合應用在一次性內視鏡產品。
2.B9303AA0000.A
晉弘科技採用類半導體製程的全自動化技術，將照明系統與鏡頭模組一體化封裝成微型鏡頭照明模組。此模組採用微型化設計，多樣的封裝樣式可供業界不同內視鏡的應用，更適合應用在一次性內視鏡產品。
DVK2117_BLUETRUM AB5616A
用於驗證中科藍訊 AB5616A BT SoC 的功能及性能。中科藍訊 AB5616A TWS 開發板主要包含了一塊 TWS 通用底板 + 兩塊 AB5616A 上蓋板，利用本產品可以快速實現 TWS 左右耳機的功能
DVK2118_BLUETRUM BT8922D2
針對 TWS 應用的開發，用於驗證中科藍訊 BT8922D2 BT SoC 的功能及性能。中科藍訊 BT8922D2 TWS 開發板主要包含了一塊 TWS 通用底板 + 兩塊 BT8922D2 上蓋板，利用本產品可以快速實現 TWS 左右耳機的功能
DVK2102-SHARK2_I.MX 8MM
以 NXP i.MX8MM 為主晶片，不僅具有高品質視頻、提供全 4K UltraHD 解析度和 HDR(Dolby Vision、HDR10 和 HLG)、提供最高水準的專業音訊保真度，具有 20 多個音訊通道，每個通道 384KHz
RSL10-COIN-GEVB
是一款藍牙® 信標開發板，具有RSL10業界功耗最低的藍牙5 SoC，以及 N34TS108低能耗溫度傳感器。開發板由電池供電，並以信標數據包的形式廣播溫度、UID 和 URL。支持無線韌體更新FOTA
NB7NQ621MMUGEVK
is a 3.3 V Dual−Mode DisplayPort (DP++), quad−channel, linear redriver supporting HDMI 2.1 Fixed Rate Link (FRL) up to 12 Gbps and TMDS up to 6 Gbps, as well as DisplayPort v1.4a Main Link (ML) up to 8.1 Gbps (HBR3).
RK3568 DDR4 EVB
内置Rockchip自研NPU RKNN，算力达0.8Tops，支持Caffe/ TensorFlow/ TFLite/ONNX/ PyTorch/Keras/ Darknet主流架構模型的一鍵轉換
DVK2111-ECHOES_S32K116
S32K116 內核為 32位Arm® Cortex®-M0+，本方案 MCU 採用 7 x 7mm LQFP48 封裝，引腳間距 0.5mm，與相同封裝的S32K1xx 系列 MCU Pin-to-Pin，具有豐富的外設資源。支援功能安全 ISO-26262 ASIL-B 等級
DVK2109-ECHOES_S32K144
針對通用汽車應用的市場需求,S32K144 內核為 32位Arm® Cortex®-M4F，本方案 MCU 採用 14 x 14mm LQFP100 封裝，引腳間距 0.5mm，與相同封裝的S32K1xx 系列 MCU Pin-to-Pin，具有豐富的外設資源。
DVK2113-NIGHTINGALE
針對車載市場，推出的OV9284 的 Nightingale DMS 解決方案，基於OV9284 的DMS模組方案,可用于駕駛員識別、人臉支付、駕駛員疲勞檢測、駕駛員和乘客監控、發動機啟動安全認證
DVK2102-DSPG-DBMD7-MODULE
offers a complete, voice processor solution for Always-On applications in mobile devices and the world of Internet of Things (IoT) that require ultra-high processing power. DBMD7 implements a triple core DSP, designed to process...
DVK2101-DSPG-DBMD4-MODULE
is an ultra-low power voice and sensor processor for battery-operated devices such as mobile handsets, IoT, wearables, etc. DBMD4Plus implements various applications such as voice trigger (VT),
DVK2007_QUALCOMM_QCC3044MODULE
is a module shared by Qualcomm QCC5144 / 3044 / 3040 chips, which is used with DVK2002 _QUALCOMM _ANC Bluetooth development board. Provide users with a complete development platform for Qualcomm...
DVK2006_QUALCOMM_QCC5141MODULE
is a module shared by Qualcomm QCC5141 / 3046 chips, which is used with DVK2002 _QUALCOMM _ANC Bluetooth development board. Provide users with a complete...
EVB_RT5710AHGQW
is a high efficiency synchronous step-down DC-DC converter. Its input voltage range is from 2.5V to 6V and provides an adjustable regulated output voltage from 0.6V to 3.4V while delivering up to 1A of output current. This document explains the function
EVB_RT4813GQUF
The RT4813 is a Boost converter with the input voltage range from 1.8V to 5.5V and provide an average output current limit range from 0.55A to 3.1A. This document explains the function and use of the RT4813 evaluation board (EVB)
DVK2005_QUALCOMM_QCC3040MODULE
is a module shared by Qualcomm QCC5144 / 3040 chips, which is used with DVK2002 _QUALCOMM _ANC Bluetooth development board. Provide users with a complete development platform for Qualcomm Bluetooth headset and TWS headset products.
EVB_RT2862GSP
is a high-efficiency current mode synchronous step-down regulator that can deliver up to 3A output current from a wide input voltage range of 4.5V to 36V. This document explains the function and use of the RT2862 evaluation board (EVB) and ...
DVK2004_QUALCOMM_QCC3046MODULE
is a module shared by Qualcomm QCC5141 / 3046 chips, which is used with DVK2002 _QUALCOMM _ANC Bluetooth development board. Provide users with a complete development platform for Qualcomm Bluetooth headset and TWS headset products.
RD0005-01
supports Richtek's E-marker ICs, and provides LED to indicate system status. The Richtek E-Marker Write Board supports selection of PD protocol 2.0 & 3.0 version and passive or active cable, and saves the setting to Vendor Information File
EVB_RT6255AHGJ6F
is a synchronous step-down converter with Advanced Constant On-Time (ACOT™) mode control. with the input voltage range from 4.5V to 18V and provides 5A output current. This document explains the function and use of the RT6255A evaluation board (EVB)
LINKIT2523HDK
基於SiP封裝的高度集成的系統，其中包含微控制器單元，超低功率的GNSS（MT2523G），雙模式藍牙，和電源管理單元（PMU）。 微控制器單元是一個的ARM Cortex-M4浮點MCU，內建4MB PSRAM和4MB快閃記憶體
STEVAL-STWINKT1B
【Feb. NPI】The STWIN SensorTile wireless industrial node (STEVAL-STWINKT1B) is a development kit and reference design that simplifies prototyping and testing of advanced industrial IoT applications such as condition monitoring and ...
STEVAL-MKSBOX1V1
【Apr. NPI】(SensorTile.box) is a ready-to-use box kit with wireless IoT and wearable sensor platform to help you use and develop apps based on remote motion and environmental sensor data, regardless of your level of expertise.
STEVAL-LLL012V1
[Jun. NPI] is composed of a power board and a connectivity board. The power board is a single stage LED driver with high power factor (HPF) and low total harmonic distortion (THD) tailored to LED power supply specifications for smart home lighting applications.
STEVAL-BCN002V1B
[Jun. NPI]features the STEVAL-BCN002V1 multi-sensor board based on BlueNRG-2 SoC Bluetooth Low Energy application processor. This sensor board has accelerometer, gyroscope, magnetometer, pressure, humidity, Time-of-Flight and...
B-L462E-CELL1
Discovery kit is a turnkey development platform for cellular IoT devices. The Discovery kit contains a low-power Discovery main board powered by an LBAD0ZZ1SE module, a global coverage antenna, and a fan-out board.
AEKD-BLINDSPOTB1
is used with the AEKD-BLINDSPOTA1 car model demonstration assembly to simulate vehicle detection in automotive blind-spot regions. It achieves this by interpreting magnetic field variations detected by a Hall sensor mounted near a stationary model car
